UNIV UDS series is the compressor which designed for construction sites. From 125Cfm up to 750Cfm .
The series all soundproof design, ease of operation, monitoring panels and protection functions.
With high performance , durable and good fuel efficient.
Availability: | |
---|---|
Quantity: | |
UNIV UDS series is the compressor which designed for construction sites. From 125Cfm up to 750Cfm .
The series all soundproof design, ease of operation, monitoring panels and protection functions.
With high performance , durable and good fuel efficient.
TECHNICAL DATA | UDS-125S | UDS-185S | UDS-265S | UDS-390S | UDS-530S | UDS-750S |
Type | Rotary twin screw | Rotary twin screw | Rotary twin screw | Rotary twin screw | Rotary twin screw | Rotary twin screw |
Free air delivery m³/min | 3.5 | 5.2 | 7.5 | 11 | 15 | 21 |
Free air delivery CFM | 125 | 185 | 265 | 390 | 530 | 750 |
Rated Operating pressure kg/cm² (bar) | 7 | 7 | 8 | 10 | 10 | 10 |
Receiver Tank capacity m³ | 0.027 | 0.027 | 0.08 | 0.105 | 0.186 | 0.186 |
Air outlet | 2x3/4" | 3x3/4" | 3x3/4" | 3x3/4" and 1x2" | 2x3/4" and 2x2" | 2x3/4" and 2x2" |
Engine | ||||||
Engine type | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke |
Model | FAW 4DW91-56G2 | Isuzu 4JB1-C | Isuzu 4JB1T-C | Cummins 6BT5.9-C150 | Cummins 6BTA5.9-C180 | Cummins 6CTA8.3-C260 |
Rated power | 41kw@2650rpm | 45kw@3000rpm | 62kw@2500rpm | 112kw@2300rpm | 132kw@2500rpm | 194kw@2200rpm |
Cylinders | 4 | 4 | 4 | 6 | 6 | 6 |
Bore x stroke (mm) | 90*100 | 93*102 | 93*102 | 102*120 | 102*120 | 114*135 |
Intake method | Nature aspirate | Nature aspirate | Turbo charged | Turbo charged | Turbo charged after-cooled. | Turbo charged after-cooled. |
Displacement (L) | 2.54 | 2.771 | 2.771 | 5.9 | 5.9 | 8.3 |
Fuel consumption (L/h) | 8.2 | 9 | 12.2 | 23.1 | 27.8 | 40.5 |
Lubrication oil capacity (L) | 7.4 | 8.5 | 8.5 | 16.3 | 16.3 | 21.9 |
Dimension and weight | ||||||
Net weight (kg) | 720 | 1180 | 1290 | 2190 | 2600 | 3450 |
Packing size LxWxH (mm) | 3100*1640*1690 | 3100*1640*1690 | 3320*1850*1750 | 4200*2000*2050 | 4500*1800*2250 | 4800*1950*2350 |
Fuel tank capacity (L) | 60 | 60 | 90 | 120 | 250 | 400 |
Download More Information | ||||||
PDF Link:![]() | ||||||
Note: Please feel free to contact with us if any more customized request ! |
High Performance: The twin-screw compressor design ensures reliable performance with consistent and stable air delivery.
Powerful Engine: Equipped with a water-cooled 4-stroke engine, providing up to 41kW of power for smooth operation in various working conditions.
Fuel Efficiency: The optimized fuel system ensures low fuel consumption of only 8.2L/h, maximizing energy savings while improving work efficiency.
Soundproof Design: Fully enclosed soundproof design effectively reduces noise, making it suitable for quiet operation on construction sites and other environments.
Durability and Protection: Built-in monitoring panels and multiple protection functions extend the service life of the equipment and reduce maintenance frequency.
Easy Operation: Simple and user-friendly control panel with real-time monitoring ensures smooth operation and efficient performance.
Construction Sites: Provides high-pressure air support for various construction projects, especially for drilling, shotcrete, and other pneumatic tools.
Mining Operations: Powers pneumatic tools used in mining, drilling, and material handling in underground and surface operations.
Port and Marine Engineering: Supplies compressed air to large equipment in port operations and offshore drilling platforms.
Oil & Gas Industry: Delivers stable air supply for drilling rigs and pneumatic machinery in the oil and gas sector.
Railway & Infrastructure Projects: Powers air tools used in railway construction, bridge building, and other large infrastructure projects.
Advanced Technology: We use state-of-the-art screw compressor technology to ensure the best performance from every unit.
Premium Quality Manufacturing: Each air compressor undergoes strict quality control to ensure we deliver high-quality, durable, and efficient products.
Energy Efficient: With fuel-saving technology, our compressors reduce operating costs and meet environmental standards, providing green and efficient compressed air solutions.
Customizable Solutions: We offer tailored products to meet specific industry requirements, ensuring maximum performance for your unique needs.
Reliable After-Sales Support: We provide comprehensive after-sales services, including installation, maintenance, and repairs, to ensure long-term stable operation.
1. What work environments are these compressors suitable for?
These compressors are ideal for construction sites, mining operations, ports, railways, and other industrial environments that require reliable compressed air.
2. Is maintenance difficult?
The compressor is designed with user-friendly maintenance in mind. Regular checks and basic cleaning are required. We also provide detailed manuals and technical support for easy upkeep.
3. What is the expected service life of the compressor?
With proper usage and maintenance, the compressor can last for over 5 years.
4. How much fuel does the compressor consume?
The fuel consumption is low, with only 8.2L/h, making it more fuel-efficient compared to traditional models.
5. Do you offer customization options?
Yes, we offer customizations based on your specific needs, including configuration, size, and additional features.
