UNIV UDS series is the compressor which designed for construction sites. From 125Cfm up to 750Cfm .
The series all soundproof design, ease of operation, monitoring panels and protection functions.
With high performance , durable and good fuel efficient.
TECHNICAL DATA | UDS-125S | UDS-185S | UDS-265S | UDS-390S | UDS-530S | UDS-750S |
Type | Rotary twin screw | Rotary twin screw | Rotary twin screw | Rotary twin screw | Rotary twin screw | Rotary twin screw |
Free air delivery m³/min | 3.5 | 5.2 | 7.5 | 11 | 15 | 21 |
Free air delivery CFM | 125 | 185 | 265 | 390 | 530 | 750 |
Rated Operating pressure kg/cm² (bar) | 7 | 7 | 8 | 10 | 10 | 10 |
Receiver Tank capacity m³ | 0.027 | 0.027 | 0.08 | 0.105 | 0.186 | 0.186 |
Air outlet | 2x3/4" | 3x3/4" | 3x3/4" | 3x3/4" and 1x2" | 2x3/4" and 2x2" | 2x3/4" and 2x2" |
Engine | ||||||
Engine type | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke |
Model | FAW 4DW91-56G2 | Isuzu 4JB1-C | Isuzu 4JB1T-C | Cummins 6BT5.9-C150 | Cummins 6BTA5.9-C180 | Cummins 6CTA8.3-C260 |
Rated power | 41kw@2650rpm | 45kw@3000rpm | 62kw@2500rpm | 112kw@2300rpm | 132kw@2500rpm | 194kw@2200rpm |
Cylinders | 4 | 4 | 4 | 6 | 6 | 6 |
Bore x stroke (mm) | 90*100 | 93*102 | 93*102 | 102*120 | 102*120 | 114*135 |
Intake method | Nature aspirate | Nature aspirate | Turbo charged | Turbo charged | Turbo charged after-cooled. | Turbo charged after-cooled. |
Displacement (L) | 2.54 | 2.771 | 2.771 | 5.9 | 5.9 | 8.3 |
Fuel consumption (L/h) | 8.2 | 9 | 12.2 | 23.1 | 27.8 | 40.5 |
Lubrication oil capacity (L) | 7.4 | 8.5 | 8.5 | 16.3 | 16.3 | 21.9 |
Dimension and weight | ||||||
Net weight (kg) | 720 | 1180 | 1290 | 2190 | 2600 | 3450 |
Packing size LxWxH (mm) | 3100*1640*1690 | 3100*1640*1690 | 3320*1850*1750 | 4200*2000*2050 | 4500*1800*2250 | 4800*1950*2350 |
| Fuel tank capacity (L) | 60 | 60 | 90 | 120 | 250 | 400 |
| Download More Information | ||||||
PDF Link： UNIV air compressor catalog.pdf | ||||||
| Note: Please feel free to contact with us if any more customized request ! | ||||||
High Performance: Offers a free air delivery of 15m³/min (530CFM) at a rated operating pressure of 10 bar, ensuring consistent air supply for demanding applications.
Fuel Efficiency: Powered by a water-cooled, 4-stroke engine, this model ensures low fuel consumption (27.8L/h), reducing operational costs.
Durable and Reliable: Built to withstand tough working environments, providing long-lasting and trouble-free service.
Soundproof Design: Designed with noise reduction in mind, making it ideal for noise-sensitive construction sites and urban areas.
Versatile Engine: Equipped with a Cummins 6BTA5.9-C180 engine with 132kW rated power, ensuring exceptional power and efficiency.
User-Friendly Operation: The compressor features a simple control panel for easy operation, with real-time monitoring for optimal performance.
Construction Sites: Reliable air supply for pneumatic tools and machinery.
Mining Operations: Powers drills, hammers, and other heavy-duty mining equipment.
Industrial Uses: Ideal for general industrial applications requiring a steady air flow.
Oil & Gas: Suitable for a range of applications in oil and gas drilling operations.
Cost-Effective: The highly fuel-efficient engine minimizes fuel costs while ensuring maximum operational uptime.
Durability: Designed to endure the toughest industrial environments, providing long-lasting performance with minimal downtime.
Noise Reduction: The soundproof design makes it ideal for urban areas and noise-sensitive applications.
User-Friendly: The control panel and monitoring system ensure easy operation and maintenance.
Trusted Engine: Powered by a reliable Cummins engine, known for its strength, longevity, and low maintenance needs.
1. What applications can this air compressor be used for?
The 530CFM air compressor is perfect for construction, mining, oil & gas industries, and other industrial tasks requiring a steady air supply.
2. How fuel-efficient is the 530CFM model?
It has a fuel consumption of 27.8L/h, making it highly fuel-efficient for its size and performance.
3. Can the 530CFM compressor be used in noise-sensitive areas?
Yes, its soundproof design makes it ideal for use in areas where noise reduction is a priority.
4. What kind of engine does it use?
The compressor is powered by a Cummins 6BTA5.9-C180 engine, providing 132kW of rated power and ensuring exceptional performance.
5. What is the weight of the compressor?
The net weight of the 530CFM air compressor is 2600 kg.
