Solar Panel | 1 × 490W, Bifacial & BC |
LFP Battery | 230Ah 12.8VDC, 2.9kW·h,with Heater,10+ years Life |
Battery Charger | 600W, Shore Power & Generator Compatible |
CCTV Pre-Wiring | Supply 12VDC, 24VDC, 48VDC & PoE Switch |
Controller | 40A MPPT with Remote Monitoring |
Mast | High-Tensile Steel, Hot Dip Galvanized, Square type, |
5 Sec 6.3 m, Manual Winch Lifting, 117km/h Wind Rating | |
Trailer | US DOT, 2'' Ball Hitch, Single Axle, 4× Outrigger, Fork Pockets |
Internal & External Anti-Corrosion Powder Coating | |
Solar Recharge Time | 5.5 hrs by Peak Solar |
Operating Time | 48 hrs @ 50W Continuous Load |
SKD 7 units in 20ft,SKD 16 units in 40ft,CKD 21 units in 40ft | |
Premium Upgrades (Available at Additional Cost):
Internal Cable Mast Electric Lifting
Victron System 4G Router 450W Inverter
2× AI Tech 180° Panoramic + 4MP PTZ/ 60-Day Retention
Active Deterrence Two-Way Audio +$95 10" Touch Panel
| Dimension(L×W×H) | Weight | Quantity | ||
| 1515mm×1450mm×1260mm (Stowed) | 775kg | 7 | ||
| 2715mm×1800mm×2935mm (Towing) | ||||
| 2715mm×2250mm×7460mm (Deployed) | ||||
Terms & Conditions:
1. Price Validity: We reserve the right to adjust the price if raw material costs or the USD/CNY exchange rate (Base Rate: 1 USD = 7 CNY) fluctuates by more than ±3%.
2. Payment: 30% deposit via T/T; 70% balance via T/T prior to dispatch.
3. Delivery: Approx. 35-45 days (20 days for design & material sourcing + 25 days for assembly). Custom designs or peak seasons require an extra 20 days. Final schedule subject to factory capacity at order confirmation.
4. Packing: PE Film wrapping with Steel Bracket reinforcement.
5. Warranty: 2 Years for Trailer Structure, LFP Battery, Solar Panels, and Controllers. 1 Year for Genset and other wear parts.
6. After-sales: We provide free parts & tech support for any issues arising from manufacturing defects or non-human factors. Damage caused by improper operation or unauthorized modification is excluded.
7. Certifications: ISO9001/14001 (Factory); CE, WMI, DOT (Product); RoHS, TUV (Components).
