UNIV UDS series is the compressor which designed for construction sites. From 125Cfm up to 750Cfm .
The series all soundproof design, ease of operation, monitoring panels and protection functions.
With high performance , durable and good fuel efficient.
TECHNICAL DATA | UDS-125S | UDS-185S | UDS-265S | UDS-390S | UDS-530S | UDS-750S |
Type | Rotary twin screw | Rotary twin screw | Rotary twin screw | Rotary twin screw | Rotary twin screw | Rotary twin screw |
Free air delivery m³/min | 3.5 | 5.2 | 7.5 | 11 | 15 | 21 |
Free air delivery CFM | 125 | 185 | 265 | 390 | 530 | 750 |
Rated Operating pressure kg/cm² (bar) | 7 | 7 | 8 | 10 | 10 | 10 |
Receiver Tank capacity m³ | 0.027 | 0.027 | 0.08 | 0.105 | 0.186 | 0.186 |
Air outlet | 2x3/4" | 3x3/4" | 3x3/4" | 3x3/4" and 1x2" | 2x3/4" and 2x2" | 2x3/4" and 2x2" |
Engine | ||||||
Engine type | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke | Water-cooled, 4 stroke |
Model | FAW 4DW91-56G2 | Isuzu 4JB1-C | Isuzu 4JB1T-C | Cummins 6BT5.9-C150 | Cummins 6BTA5.9-C180 | Cummins 6CTA8.3-C260 |
Rated power | 41kw@2650rpm | 45kw@3000rpm | 62kw@2500rpm | 112kw@2300rpm | 132kw@2500rpm | 194kw@2200rpm |
Cylinders | 4 | 4 | 4 | 6 | 6 | 6 |
Bore x stroke (mm) | 90*100 | 93*102 | 93*102 | 102*120 | 102*120 | 114*135 |
Intake method | Nature aspirate | Nature aspirate | Turbo charged | Turbo charged | Turbo charged after-cooled. | Turbo charged after-cooled. |
Displacement (L) | 2.54 | 2.771 | 2.771 | 5.9 | 5.9 | 8.3 |
Fuel consumption (L/h) | 8.2 | 9 | 12.2 | 23.1 | 27.8 | 40.5 |
Lubrication oil capacity (L) | 7.4 | 8.5 | 8.5 | 16.3 | 16.3 | 21.9 |
Dimension and weight | ||||||
Net weight (kg) | 720 | 1180 | 1290 | 2190 | 2600 | 3450 |
Packing size LxWxH (mm) | 3100*1640*1690 | 3100*1640*1690 | 3320*1850*1750 | 4200*2000*2050 | 4500*1800*2250 | 4800*1950*2350 |
| Fuel tank capacity (L) | 60 | 60 | 90 | 120 | 250 | 400 |
| Download More Information | ||||||
PDF Link： UNIV air compressor catalog.pdf | ||||||
| Note: Please feel free to contact with us if any more customized request ! | ||||||
High-Performance: The 265CFM Diesel Portable Screw Air Compressor provides efficient and reliable air delivery with a free air delivery of 7.5m³/min (265CFM), making it ideal for high-demand industrial applications.
Durable and Robust: Equipped with a rotary twin screw design and powered by a powerful Isuzu 4JB1T-C engine, offering 62kW of rated power for superior performance in tough environments.
Fuel Efficient: This model is designed for optimal fuel consumption with only 12.2L/h, ensuring cost-effective operation over long periods.
Soundproof Design: Features a fully enclosed soundproof casing that minimizes noise levels, providing a quieter operation suitable for construction sites and other noise-sensitive areas.
Easy Operation and Maintenance: Includes a user-friendly monitoring panel for easy operation and built-in protection functions to ensure continuous operation with minimal downtime.
Portability: The compact and durable design makes it easy to transport and deploy on construction sites, mining operations, and industrial jobs.
Construction Projects: Provides reliable compressed air for a wide range of construction tools and equipment, including pneumatic drills and breakers.
Mining Operations: Ideal for powering mining machinery and equipment, improving productivity and efficiency in underground and surface mining.
Industrial Use: Perfect for various industrial applications requiring high-volume compressed air, such as air-powered tools, sandblasting, and more.
Railway & Infrastructure: Powers air tools used in railway construction and other large infrastructure projects, ensuring consistent and efficient performance.
Oil & Gas: Supplies compressed air for operations in the oil and gas industry, including drilling, well services, and pipeline maintenance.
Top Quality Construction: Our air compressors are built using advanced technology, ensuring maximum performance, reliability, and durability.
Cost-Effective Operation: With excellent fuel efficiency, this model offers reduced operational costs while maintaining high performance.
Robust Power Source: Powered by the reliable Isuzu engine, designed for heavy-duty applications and long-term use.
Environmentally Friendly: Optimized fuel consumption and low noise output contribute to a more sustainable, eco-friendly operation.
Comprehensive After-Sales Support: We offer full after-sales service, including installation, maintenance, and troubleshooting, to ensure your equipment runs smoothly for years.
1. What is the free air delivery of this compressor?
The 265CFM model delivers 7.5m³/min (265CFM) of free air, making it suitable for medium to heavy-duty industrial applications.
2. What is the fuel consumption of the 265CFM model?
The fuel consumption is optimized to 12.2L/h, providing excellent fuel efficiency for extended operation.
3. Can this compressor be used on construction sites?
Yes, the 265CFM Diesel Portable Screw Air Compressor is designed for construction sites, featuring a soundproof design for reduced noise and increased portability.
4. Is the compressor easy to maintain?
Yes, the compressor includes a user-friendly control panel and built-in protection features to make maintenance simple and reduce downtime.
5. What kind of engine does the 265CFM model have?
The model is powered by an Isuzu 4JB1T-C engine, offering a rated power of 62kW and excellent performance in demanding conditions.
