UST-1800 Mobile Trailer NEW Green Energy Solar Powered Portable Light Tower UST-1800 Mobile Trailer NEW Green Energy Solar Powered Portable Light Tower

loading

UST-1800 Mobile Trailer NEW Green Energy Solar Powered Portable Light Tower

5 0 Reviews
Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
UST-1800 mobile solar trailer devoted into clean energy's application in emergency use lighting, surveillance and telecom. It is towable, easy to deploy and without fuel cost, no noise, no smell....
  • UST-1800

Availability:
Quantity:

Stronger double axle construction!Heavy duty 9m hydraulic mast!This model designed for mining,oil filed industry.which produce 13.65kW per day and support 1200W LED lighting every night.

UST-1800 SERIES:

1. 6 pcs Solar panel design trailer

2. Optional 7-12m manual / electric telescopic mast

3. Mobile trailer with Australian / European / American standard



Technical Data



ECO

PLUS

AC & PLUG

HYDRAULIC & HEAVY

HYDRAULIC & AC

Model

UST-1800E5MS

UST-1800S5MS/D

UST-1800A5MS/D

UST-1800A5HD

UST-1800AS9HD

Type of Lights

6X100W LED

6X100W LED

6X150W LED

6X150W LED

6X150W LED

Lights Output

DC48V, 90,000LUMS

DC48V, 90,000LUMS

DC48V, 135,000LUMS

DC48V, 135,000LUMS

DC48V, 135,000LUMS

Solar Panel

Monocrystalline Silicon

Monocrystalline Silicon

Monocrystalline Silicon

Monocrystalline Silicon

Monocrystalline Silicon

Rate Power

6x455W

6x455W

6x455W

6x455W

6x455W

Type of Battery

Gel-battery

Gel-battery

Gel-battery

Gel-battery

Gel-battery

PV Controller

MPPT 60A

MPPT 60A

MPPT 60A

MPPT 60A

MPPT 60A

No. of Battery

8X200AH DC12V

8X250AH DC12V

8X250AH DC12V

8X250AH DC12V

8X250AH DC12V

Battery Capacity

400AH

500AH

500AH

500AH

500AH

System Voltage

DC48V

DC48V

DC48V

DC48V

DC48V

Mast

Telescopic, Galvanized

Telescopic, Galvanized

Telescopic, Galvanized

Telescopic, Galvanized

Telescopic, Galvanized

Maximum Height

7m/9m Optional

7m/9m Optional

7m/9m Optional

7m

9m/10m/12m Optional

Wind Rating Speed

100KM/H

100KM/H

100KM/H

100KM/H

100KM/H

Lifting System

Manual / Electric

Manual / Electric

Manual / Electric

Hydraulic

Hydraulic

AC Output

/

/

3000W

3000W

3000W

Battery Charger

/

/

34A

34A

2x2500W

Axle NO:

Single axle

Single axle / Dual axle

Single axle / Dual axle

Dual axle

Dual axle

Tyre and Rim

15 inch

15 inch

15 inch

15 inch

15 inch

Stabilisers

4PCS Manual

4PCS Manual

4PCS Manual

4PCS Manual

4PCS Manual

Tow Hitch

50mm ball / 70mm Ring

50mm ball / 70mm Ring

50mm ball / 70mm Ring

50mm ball / 70mm Ring

50mm ball / 70mm Ring

Color

Customized

Customized

Customized

Customized

Customized

Working Temperature

-35-60 C

-35-60 C

-35-60 C

-35-60 C

-35-60 C

Operate Time

22 hours

28 hours

19 hours

19 hours

19 hours

Charge Time (Solar)

8 hours

8 hours

8 hours

8 hours

8 hours

Charge Time (AC)

/

10 hours

10 hours

10 hours

8 hours

Dimensions

3630x2195x2525mm @7m

3630x2195x2860mm @9m

3630x2240x2525mm @7m

3630x2240x2525mm @7m

3630x2240x2860mm @9m

3787x2240x2525mm @7m

3787x2240x2410mm @9m

Dry Weight

1785kg

1875kg

1875kg

1985kg

2250kg

20GP container

2units

2units

2units

2units

2units

40HQ container

4units

4units

4units

4units

4units

Download UST-1800:
UST-1800.pdf
Download: UNIV Lighting towers & CCTV catalog .pdf
Note: Please feel free to contact with us if any more customized request !
