High Lummins Diesel Lighting Tower
The UGT-2000 mobile light tower is a metal halide lighting solution for outdoor, remote locations.
1. 4*10000w matel halide lamps, Delivering 440,000 lums
2. 7.5M aluminium mast with hydraulic lifting system
3. Full bunded design
4. AC power output
5. Low noise and fuel consumption
6. Australian / European / American standard
| Model | UGT-1600 | GDQ5A-4R | UGT-4000 | UGT-2000 | UGT-10L | UGT-10QL | |||
| Lighting & Mast | |||||||||
| Type of Lights | 4x400W MH | 4x400W MH | 4x1000W MH | 4x500W LED | 4x500W LED | 8x300W LED | |||
| Lights Output | |||||||||
| Lights Voltage | AC220V | AC220V | AC220V | AC220V | AC220V/DC48V | AC220V/DC48V | |||
| Maximum Height | 4.5m | 6.5m | 7/9M | 9/10M | 9/10M | 8.5M | |||
| Wind Rating Speed | 110km/h | 110km/h | 110km/h | 110km/h | 110km/h | 110km/h | |||
| Lifting System | Manual/electric | Manual/electric | Manual/electric/hydraulic | hydraulic | hydraulic | all hydraulic | |||
| Mast Rotation | / | / | / | manual 360 | manual 360 | Hydraulic 360 | |||
| Lamp Rotation | manual | manual | manual | electric Tilt | electric Tilt | Hydraulic tilt | |||
| Engine | |||||||||
| Engine model | 186FA | 186FA | Perkins 403D-11G | Perkins 403D-11G | Perkins 403D-11G | Perkins 403D-11G | |||
| RPM | 3000/3600rpm | 3000/3600rpm | 1500/1800rpm | 1500/1800rpm | 1500/1800rpm | 1500/1800rpm | |||
| Type of engine | Air cooled | Air cooled | Water cooled | Water cooled | Water cooled | Water cooled | |||
| Rate Power | 5kw | 5kw | 10kw standby | 10kw standby | 10kw standby | 10kw standby | |||
| Fuel tank | 12.5L | 12.5L | 100L | 100L | 120L | 300L | |||
| Noise level | 68db @7m | 65db @7m | 65db @7m | 65db @7m | 63db @7m | 63db @7m | |||
| Trailer | |||||||||
| Axle NO: | Single axle | Single axle | Single axle | Single axle | Single axle | Single axle | |||
| Tyre and Rim | 12 inch | 14 inch | 15 inch | 15 inch | 15 inch | 15 inch | |||
| Stabilisers | 4PCS Manual | 4PCS Manual | 4PCS Manual | 4PCS Manual | 4PCS Manual | 4PCS Manual | |||
| Tow Hitch | 50mm ball / 70mm Ring | 50mm ball / 70mm Ring | 50mm ball / 70mm Ring | 50mm ball / 70mm Ring | 50mm ball / 70mm Ring | 50mm ball / 70mm Ring | |||
| Working Temperature | -30-70 C | -30-70 C | -40-70 C | -40-70 C | -40-70 C | -40-70 C | |||
| Dimensions & Weight | |||||||||
| Dimensions | 1350x900x2550mm | 2378x1470x2490mm | 3800x1470x2490mm | 3450x1550x2500mm | 2730x1583x2500mm | 3750x1700x2500 | |||
| Dry Weight | 350kg | 650kg | 1280kg | 1550kg | 1650kg | 1920kg | |||
| 20GP container | 16 | 6 | 3 | 3 | 3 | 2 | |||
| 40HQ container | 32 | 14 | 8 | 7 | 7 | 5 | |||
| Download |  UNIV Lighting towers & CCTV Catalog.pdf | ||||||||
